ISO9001:2015, ISO 13485:2016, GMP and CE
We are top MVA Kits Manufacturers in India. We offer very competitive price for Manual Vacuum Aspiration Kits. Our Manual Aspirator Kit is manufactured from high quality material. MVA Syringe is made from medical grade Polypropylene and Silicone Rubber. Each component is strictly quality checked before assembly. We provide OEM for MVA Kit. We are one of the leading manufacturers and exporters of MVA Kits in India. Largest Manual Vacuum Aspirator Kit Manufacturers in India. We offer MVA Kit at very affordable price and high quality. Our Manual Vacuum Aspirator Kits are exported to various countries. Customized packing will also be available MVA Kit. Manual Vacuum Aspirator Kit Manufacturers, Manual Vacuum Aspirator Kit Exporters in India, Manual Vacuum Aspirator Kit Suppliers in India.
Manual Vacuum Aspirator Kit (MVA) Kit is containing of:
Autoclavable Double Valve MVA (Manual Vacuum Aspirator) Syringe with a capacity of 60ml.
All accessories including silicone oil.
Karman Cannula sizes 4, 5, 6, 7, 8, 9, 10 & 12, one each
Detailed information of Double Valve MVA Syringe:
|
Components of Manual Vacuum Aspirator Double Pinch Valve Syringe, 60ml |
Detailed information |
| Plunger |
A component that inserts into the cylinder and when pulled creates the vacuum. Material: Polypropylene. |
| Cylinder |
Main holding vessel of the aspirator. Material: Polypropylene |
| Valve Body |
Case to enclose the valve mechanism. Material: Polypropylene. |
|
Collar Stop |
Clip on top of the cylinder, which prevents the plunger from being removed from the cylinder. Material: Polypropylene |
| O-ring |
A rubber ring(Black) is inserted onto the end of the plunger making the plunger slide into The cylinder and creating a vacuum. Material: Silicone Rubber / Buna-Nitrile rubber(Synthetic Rubber) |
| Buttons |
Knobs when pressed close off the liner that creates a vacuum when the plunger is pulled. Material: Polypropylene |
| Liner Clamp |
A mechanism that closes off the liner, which creates a vacuum in the cylinder when the plunger is pulled. Material: Polypropylene |
| Liner |
The soft tubular part clamps off to create the vacuum. Material: Poly-dimethylsiloxane (Silicone Rubber) |
| Valve Cap |
The component at the end of the valve body. Helps to hold the cannulae or adapter in place. Material: Polypropylene |
Polypropylene Barrel Capacity 60 ML.
Suction capacity: Provides above 24 inches of hg ( mercury)/609.6 mm of hg( mercury) Vacuum. Maintain this vacuum for more than Sixty minutes.
Compatible with fixed adapter Karman cannulae sizes 4-12 mm.
The valve liner is removable by opening a hinged valve body. Double locking valve allowing the creation of vacuum prior to the procedure. The valve liner provides a clear fluid path.
The aspirator features a secure stopping mechanism for the plunger when pulled. The collar stop is able to be displaced or removed for removal of plunger. A cylinder is marked in 10cc increments to measure evacuated uterine contents.
With an ergonomic handle.
Aspirators is able to be boiled and steam sterilized (autoclaved) at 250°F or 121°C. Can be sterilized with STERRAD 100s and can be processed by standard cold methods.
Shelf life: 5 years from the month of manufacture.
Suitable to be reused a minimum of 25 - 50 times under normal use and maintenance.
ALSO AVAILABLE SAME SET WITH SINGLE-VALVE MVA SYRINGE
